Manhole Ladders – Wall Mount – Optional Wall Brackets – 7″ (178 mm) offset – Condux
All ladders are manufactured of steel. The rungs pass through the side rails and are riveted or welded.
Ladders are hot dip galvanized. Rated at 300 lbs. (136 kg).
Features:
- 5/8″ (16 mm) diameter deformed rungs on 12″ (305 mm) centers
- 14″ (356 mm) clear between side rails
- 2 x 1 x 1/8″ (51 x 25 x 3 mm) channel side rails
- Furnished with 4 unattached floor/ceiling brackets
- Wall mounting brackets may be used (sold separately)
- Approx. weight is 5.5 lbs. (2.5 kg) per foot of length
NOTE: This item is made-to-order and is not returnable.
Description
Ordering Information
| Part Number | Description |
|---|---|
| 08382001 | Manhole Ladder, wall mount, 7.0′ (2.1 m) long |
| 08382101 | Manhole Ladder, wall mount, 8.0′ (2.4 m) long |
| 08382301 | Manhole Ladder, wall mount, 10.0′ (3.0 m) long |
| 08382501 | Manhole Ladder, wall mount, 12.0′ (3.7 m) long |
| 08382701 | Manhole Ladder, wall mount, 14.0′ (4.3 m) long |
| 08382901 | Manhole Ladder, wall mount, 16.0′ (4.9 m) long |
| 08384101 | Manhole Ladder, wall mount, 18.0′ (5.5 m) long |
| 08384201 | Manhole Ladder, wall mount, 20.0′ (6.1 m) long |
| 08382902 | Optional Wall Brackets – 7″ (178 mm) offset |
Additional information
| Weight | 1.8 lbs |
|---|---|
| Dimensions | 8.25 × 1.5 × 2.62 in |
| Fiber Count | 8F |
