Cat.5E 110 Type Patch Panel 24Port Rackmount

Name: Cat.5E 110 Type Patch Panel 24Port Rackmount
SKU: ATDS102197
Price: 19.64 USD
Availability: InStock

$19.64

SKU: ATDS102197 Categories: Patch Panels, Rack Mount Patch Panels

Description

UL approved

19 inch 1U rackmount

Meets TIA/EIA-568B.2/568B.2-1 Cat.5E, ISO/IEC 11801 and EN 50173-1 specification

Support T568A & B wiring

Wire diameter: 22 ~ 26AWG

Insulation diameter range: 0.70 to 1.40mm

Jack contacts: Phosphor bronze, 50micron gold plate over nickel plating.

IDC contacts: Phosphor bronze, 50micron gold plate over nickel plating.

Safety: UL1863

Flammability: UL 94 VO

Operating temperature: -40 to +70 degree Celsius

Weight: 1.55LBS

Mounting Hinge: 102215

25 years warranty
