Cat.5E 110 Type Patch Panel 12Port Rackmount

Name: Cat.5E 110 Type Patch Panel 12Port Rackmount
SKU: ATDS102196
Price: 14.22 USD
Availability: InStock

$14.22

SKU: ATDS102196 Categories: Patch Panels, Rack Mount Patch Panels

Description

UL listed

19 inch 1U rackmount

Meets TIA/EIA-568B.2/568B.2-1 Cat.5E ISO/IEC 11801 and EN 50173-1 specification

Support T568A & B wiring

Wire diameter : 22 ~ 26AWG

Insulation diameter range : 0.70 to 1.40mm

Jack contacts : Phosphor bronze, 50micron gold plate over nickel plating.

IDC contacts : Phosphor bronze, 50micron gold plate over nickel plating.

Safty : UL1863

Flamability : UL 94 VO

Operating temperature : -40 to +70 dgree Celsius

Weight : 1.55LBS

Mounting Hinge: 102215

25 years warranty
