7m LC/UPC-SC/UPC Singlemode Simplex LSZH 2.0mm Fiber Optic Patch Cable
$1.99
Description
| Connector Type | LC-SC Singlemode |
| Polishing | UPC |
| Return Loss | 55dB |
| Insertion Loss | 0.30dB |
| Ferrule Material | Ceramic (zirconia) |
| Ferrule Diameter | 1.25 mm / 2.5 mm |
| Body type | Simplex |
| Nominal Diameter Core | 9/125 µm |
| Jacket Material | LSZH |
| Operation Temperature Range | -20°C +70°C |
| Cable Diameter | 2.0mm |
- Used to connect patch panels and/or network devices that utilize LC to SC style connectors and require 9/125 Single mode cabling* 100% tested* Test report included in each cable
Additional information
| Weight | 0.167 lbs |
|---|---|
| Connector Type | LC/UPC-SC/UPC |
| Cable Type | Simplex |
| Fire Rating | LSZH |
| Fiber Count | 2F |
| Mode | Singlemode |
| AWG | 30 AWG |
