It’s the heart and soul of your operation. Day in, day out delivering quality video, audio and data to your customers. There’s no bigger investment in your system than your headend electronics. Now think about what goes into a great headend: high-quality electronic equipment with state of the art design and engineering, equipment that you’re proud to see on the headend rack. Sleek and stylish on the outside. Powerful and reliable on the inside. Versatile and practical all around. Agile to meet your changing needs and able to reach your bandwidth requirements with capacity to grow. Specs to make you smile and performance to make your customers sit up and notice. Well, how about that: We’ve just described the Macom Professional Series headend products.

PM-SE : BTSC Stereo Encoder

Features

High quality, low noise MTS/BTSC stereo encoder is compatible with most commercially available modulators
28dB minimum separation from .5 to 5kHz provides high fidelity audio
Simple, no-adjustment plug-and-play operation eliminates time intensive set-up procedures
Micro chip encoder and surface mount components provide increased reliability
Ultra compact design connects directly to modulator, eliminating the need for additional rack space
External transformer power supply reduces heat buildup in encoder, providing prolonged product life

Specifications

Bandwidth	20~13,000Hz
Audio Input Left	1Vp-p
Audio Input Right	1Vp-p
Video Input Loop	1Vp-p
Composite Stereo Output	2.2Vp-p
Third Harmonic Distortion	1%
Signal to Noise Ratio	65dBc
Frequency Response	1dB
Stereo Separation	28dB (@ 0.5~5kHz) 25dB (@ 0.1~10kHz)
Power Input	5VDC
Power Required	60mA
Power Type	Adapter, UL Approved
AC Input	120VAC @ 60Hz
DC Output	5Vdc @ 60mA
Dimensions	2.2˝(H) x 1.7˝(W) x 1.5˝(D)
Weight	0.6 lbs.
