Cat 5E 110 Type Patch Panel 12Port Vertical w/Bracket SKU: ATDS102195
Cat 5E 110 Type Patch Panel 12Port Vertical w/Bracket SKU: ATDS102195 - Image 2
Cat 5E 110 Type Patch Panel 12Port Vertical w/Bracket SKU: ATDS102195 - Image 3

Cat 5E 110 Type Patch Panel 12Port Vertical w/Bracket SKU: ATDS102195

$14.33

Cat 5E 110 Type Patch Panel 12Port Vertical w/Bracket

90 in stock

Compare
SKU: ATDS102195 Categories: ,

Description

Description

Spec drawing

  • Mounting Bracket Included
  • UL listed
  • Meets TIA/EIA-568B.2/568B.2-1 Cat 5E ISO/IEC 11801 and EN 50173-1 specification
  • Support T568A : B wiring
  • Wire diameter : 22 ~ 26AWG
  • Insulation diameter range : 0.70 to 1.40mm
  • Jack contacts : Phosphor bronze, 50micron gold plate over nickel plating.
  • IDC contacts : Phosphor bronze, 50micron gold plate over nickel plating.
  • Safty : UL1863
  • Flamability : UL 94 VO
  • Operating temperature : -40 to +70 dgree Celsius
  • Weight : 0.85LBS
  • 25 years warranty
  • Carton qty: 24
  • Carton weight: 23 LBS
  • Dimensions : 10″(H) x 2 1/4″ (W) x 1 3/4″ (D)

    • Additional information

    Weight 1.05 lbs
