MarineTuff Cat 6A, S/FTP, 4 Pr 23 BC,FMPE Ins, LSZH, Indoor, LR certified (Category 7 Cable) – Belden (MA6ASFL)

Call for Price

Marine Ethernet Cat 6A Cable, 4 Pr 23AWG Annealed Bare Copper, Foam Polyethylene Insulation, S/FTP, Low Smoke Zero Halogen (SHF1) Jacket, Indoor Shipboard, LR certified
Belden offers a broad range of Category 7 cables for your most bandwidth-intensive applications. These ultra-reliable cables support the growing demand for high-performance networking.

Compare
SKU: BELDEN-MA6ASFL Categories: , ,
Belden

Description

Features & Benefits

  • Built-in reliability: Ultra-robust design ensures long lifespan of cable
  • Future-readiness: With 10Gb/s+ performance, Category 7 cables support growing bandwidth demands and future network expansion
  • Signal integrity: Additional shielding protects signal from interference

Specifications

Product Overview

Suitable Applications

Shipbuilding, in-cabin passenger Wi-Fi, high-bandwidth IPTV, PoE lighting, device charging stations, onboard security cameras, etc.

Physical Characteristics (Overall)

Conductor

AWG Stranding Material No. of Pairs
23 Solid BC – Bare Copper 4

Conductor Count

8

Total Number of Pairs

4

Insulation

Material Nominal Diameter
PO – Polyolefin (Foam) 1.35 mm

Color Chart

Number Color
Pair 1 White & Blue
Pair 2 White & Orange
Pair 3 White & Green
Pair 4 White & Brown

Inner Shield

Element Type Material Coverage [%]
Individual Shielded Pair Tape Bi-Laminate (Alum+Poly) 100%

Outer Shield

Type Material Coverage [%] Drainwire Material Drainwire AWG
Braid Tinned Copper (TC) 30% Tinned Copper 28 AWG

Outer Jacket

Material Nominal Diameter Diameter +/- Tolerance
LSZH – Low Smoke Zero Halogen (SHF1) 7.8 mm 0.3 mm

Construction and Dimensions

Min Elongation at Breakof Jacket

125 %

Min Tensile Strength of Jacket

9 MPa

Min Tensile Strength of Jacket Aged

30 %

Min Elongation at Break of Jacket Aged

30 %

Electrical Characteristics

Conductor DCR

Max. Conductor DCR Max DCR Unbalanced Between Pairs [%] Max. DCR Unbalanced Within Pair [%]
95 Ohm/km 4 % 2 %

Capacitance

Max. Capacitance Unbalance Max. Mutual Capacitance
160 pF/100m 56 pF/m

Insulation Resistance

5000 MOhm.m

Impedance

Nominal Characteristic Impedance
100 Ohm

Delay

Max. Delay Skew Nominal Velocity of Propagation (VP) [%]
45 ns/100m 77%
High Frequency

Frequency [MHz] Max. Insertion Loss (Attenuation) Min. NEXT [dB] Min. PSNEXT [dB] Min. ACR [dB]

Brand

Belden
