MarineTuff Cat7 S/FTP, 4 Pr #23 Str BC, FMPE Ins, LSZH Jkt (Category 7 Cable) – Belden (50007TSF)

Call for Price

Industrial Marine Ethernet Cat7 S/FTP, 4 Pr 23AWG Stranded Bare Copper, FoamPolyethylene Insulation, Low Smoke Zero Halogen (SHF1) Jacket, DNV
Belden offers a broad range of Category 7 cables for your most bandwidth-intensive applications. These ultra-reliable cables support the growing demand for high-performance networking.

Compare
SKU: BELDEN-50007TSF Categories: , ,
Belden

Description

Features & Benefits

  • Built-in reliability: Ultra-robust design ensures long lifespan of cable
  • Future-readiness: With 10Gb/s+ performance, Category 7 cables support growing bandwidth demands and future network expansion
  • Signal integrity: Additional shielding protects signal from interference

Specifications

Product Overview

Suitable Applications

marine, harsh environment, IIoT, factory or process automation, IP cameras and devices, data communication, etc.

Construction Details

Conductor

Size Stranding Material No. of Pairs
23 Stranded BC – Bare Copper 4

Insulation

Material Color Code
PO – Polyolefin (Foam) White / Blue, White / Orange, White / Green, White / Brown

Inner Shield

Shield Type Material
Tape Bi-Laminate (Alum+Poly)

Outer Shield

Shield Type Material
Braid Tinned Copper (TC)

Outer Jacket

Material Nom. Diameter
LSZH – Low Smoke Zero Halogen (Flame Retardant) 9.0 mm (0.35 in)

Electrical Characteristics

Electricals

Max. Conductor DCR Max. Capacitance Unbalance Nom. Characteristic Impedance
95 Ohm/km (29 Ohm/1000ft) 160 pF/100m 100 Ohm

Delay

Max. Delay Max. Delay Skew
538 ns/100m @100MHz 25 ns/100m

High Frequency

Part Numbers

Frequency [MHz] Max. Insertion Loss (Attenuation) Min. NEXT [dB] Min. PSNEXT [dB] Min. ACRF (ELFEXT) [dB] Min. PSACRF (PSELFEXT) [dB] Min. RL (Return Loss) [dB] Min. TCL [dB] Min. ELTCTL [dB]
1 40 35
4 3.7 dB/100m 78 75 78 75 23 34 23
8 5.2 dB/100m 78 75 77.2 74.2 24.5 31 16.9
10 5.9 dB/100m 78 75 75.3 723 25 30 15
16 7.4 dB/100m 78 75 71.2 68.2 25 28 10.9
20 8.3 dB/100m 78 75 69.3 66.3 25 27 9
25 9.3 dB/100m 78 75 67.3 64.3 24.3 26 7
31.25 10.4 dB/100m 78 75 65.4 62.4 23.6 25.1
Item # Color Putup Type Length EAN
50007TSF 010305M Black Reel 305 m
50007TSF-A500 Black Reel 500 m 8719605188014
50007TSF-A1000 Black Reel 1,000 m 8719605189097
50007TSF 006305M Blue Reel 305 m
50007TSF 008305M Gray Reel 305 m
