BE41231 – Lead Wire, 0.44mm² Str BC, PVC Ins, 70°C

Call for Price

parts-139

(SKU: 103-191021001) – MicroFlow drive wheel A 2.0 mm incl – o-ring – Microfiber Blowers for Microduct Cable Installation – Microfiber Blowers – Microduct Fiber Cable Blowers – FTTH – FTTH Blowers – Fiber to the Home – Fiber to the Home Blowers – Fremco

$354.90

parts-138

(SKU: 103-191021002) – MicroFlow drive wheel B 2.5 mm incl – o-ring – Microfiber Blowers for Microduct Cable Installation – Microfiber Blowers – Microduct Fiber Cable Blowers – FTTH – FTTH Blowers – Fiber to the Home – Fiber to the Home Blowers – Fremco

$354.90

parts-139

(SKU: 103-191021003) – MicroFlow drive wheel C 3.0 mm incl – o-ring – Microfiber Blowers for Microduct Cable Installation – Microfiber Blowers – Microduct Fiber Cable Blowers – FTTH – FTTH Blowers – Fiber to the Home – Fiber to the Home Blowers – Fremco

$354.90

parts-136

(SKU: 103-191021004) – MicroFlow drive wheel D 6.0 mm incl – o-ring – Microfiber Blowers for Microduct Cable Installation – Microfiber Blowers – Microduct Fiber Cable Blowers – FTTH – FTTH Blowers – Fiber to the Home – Fiber to the Home Blowers – Fremco

$354.90

parts-119

(SKU: 103-171114001) – MicroFlow sensor arm set 1.5 mm – Microfiber Blowers for Microduct Cable Installation – Microfiber Blowers – Microduct Fiber Cable Blowers – FTTH – FTTH Blowers – Fiber to the Home – Fiber to the Home Blowers – Fremco

$321.10

parts-118

(SKU: 103-171114002) – MicroFlow sensor arm set 2.0 mm – Microfiber Blowers for Microduct Cable Installation – Microfiber Blowers – Microduct Fiber Cable Blowers – FTTH – FTTH Blowers – Fiber to the Home – Fiber to the Home Blowers – Fremco

$321.10

Description

Product Overview

Suitable Applications: IEC 189-3 Equipment wire 70C

Physical Characteristics (Overall)

Conductor
Stranding Material Cross Section Construction n x D
Stranded BC – Bare Copper 0.44 mm² 14×0.20 mm
Conductor Count: 1
Insulation
Type Material Nominal Diameter Diameter +/- Tolerance Min. Wall Thickness
Insulation PVC – Polyvinyl Chloride 2.05 mm 0.08 mm 0.4 mm

Electrical Characteristics

Conductor DCR
Element Max. Conductor DCR
Conductor(s) 45 Ohm/km
Min Insulation Resistance: 10 MOhm*km

Temperature Range

Operating Temp Range (Flexible Install): -25°C To +70°C

Standards

UL AWM Style Compliance: N/A
Military Compliance: N/A

Applicable Environmental and Other Programs

Environmental Space: Indoor
EU CE Mark: Yes

Flammability, LS0H, Toxicity Testing

UL voltage rating: N/A

Related Part Numbers

Variants
Item # Color Put-Up Type Length EAN
BE41231.003000 Black Reel 3,000 m 8719605025241
BE41231.103000 Blue Reel 3,000 m 8719605025333
BE41231.063000 Brown Reel 3,000 m 8719605025302
BE41231.093000 Gray Reel 3,000 m 8719605025326
BE41231.083000 Red Reel 3,000 m 8719605025319
BE41231.053000 Violet Reel 3,000 m 8719605025296
BE41231.033000 White Reel 3,000 m 8719605025272
BE41231.013000 White, Green Ring Reel 3,000 m 8719605025258
BE41231.023000 White, Red Ring Reel 3,000 m 8719605025265
BE41231.043000 Yellow Reel 3,000 m 8719605025289
BE41231.163000 Yellow, Green Ring Reel 3,000 m 8719605025340

History

Update and Revision: Revision Number: 0.139 Revision Date: 04-08-2022
