8890 - Lead Wire, #24 Str TC, EPDM Ins

8890 – Lead Wire, #24 Str TC, EPDM Ins

Call for Price

Compare
SKU: 8890 Categories: , , ,

Description

Product Overview

Suitable Applications: used as test probe lead for electrical and electronic measuring for test equipment

Construction Details

Conductor
Element No. of Elements Size Stranding Material
Conductor(s) 1 24 45×40 TC – Tinned Copper
Insulation
Material Nom. Thickness
EPDM – Ethylene Propylene Diene Monomer 0.019 in (0.48 mm)
Overall Cable Diameter (Nominal): 0.066 in (1.7 mm)

Electrical Characteristics

Electricals
Nom. Conductor DCR
24.2 Ohm/1000ft
Voltage
Voltage Rating Breakdown Voltage
1000 V 10,000 V

Mechanical Characteristics

Bend Radius
Stationary Min. Installation Min.
0.27 in (6.9 mm) 0.27 in (6.9 mm)
Max. Pull Tension: 5.9 lbs (2.7 kg)
Bulk Cable Weight: 3.3 lbs/1000ft

Standards and Compliance

Sustainability: CA Prop 65
European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC Compliance: China RoHS II (GB/T 26572-2011)

Product Notes

Notes: 10000 V Breakdown

History

Update and Revision: Revision Number: 0.458 Revision Date: 01-20-2023

Part Numbers

Variants
Item # Color Putup Type Length UPC
8890 010100 Black Reel 100 ft 612825217534
8890 010500 Black Reel 500 ft 612825217541
8890 002100 Red Reel 100 ft 612825217510
8890 002500 Red Reel 500 ft 612825217527
