| Suitable Applications: | Aerospace, analog video |
| RG Type: | 179 |
| Size | Stranding | Nom. Diameter | Material |
|---|---|---|---|
| 30 AWG | 7×38 | 0.012 in | SCCS – Silvered Copper Covered Steel |
| Material | Nom. Insulation Diameter | Color Code |
|---|---|---|
| PTFE – Polytetrafluoroethylene | 0.063 in (1.6 mm) | White |
| Layer | Outer Shield Type | Material | Coverage |
|---|---|---|---|
| 1 | Braid | Silvered Copper (SC) | 95% |
| Material | Nom. Diameter |
|---|---|
| FEP – Fluorinated Ethylene Propylene | 0.100 in (2.54 mm) |
| Overall Cable Diameter (Nominal): | 0.100 in (2.54 mm) |
| Frequency | Nom. Attenuation |
|---|---|
| 1 MHz | 3.0 dB/100ft |
| 10 MHz | 5.3 dB/100ft |
| 50 MHz | 8.5 dB/100ft |
| 100 MHz | 10.0 dB/100ft |
| 200 MHz | 12.5 dB/100ft |
| 400 MHz | 16.0 dB/100ft |
| 700 MHz | 19.7 dB/100ft |
| 900 MHz | 22.3 dB/100ft |
| 1000 MHz | 24.0 dB/100ft |
| Frequency | Max. Power Rating |
|---|---|
| 50 MHz | 1,250 W |
| 100 MHz | 865 W |
| 200 MHz | 599 W |
| 400 MHz | 415 W |
| 700 MHz | 308 W |
| 900 MHz | 270 W |
| 1,000 MHz | 255 W |
| Nom. Conductor DCR | Nom. Outer Shield DCR | Nom. Capacitance Cond-to-Shield |
Nom. Characteristic Impedance | Nom. Velocity of Prop. |
|---|---|---|---|---|
| 232 Ohm/1000ft (761 Ohm/km) | 8.5 Ohm/1000ft (28 Ohm/km) | 19.5 pF/ft (64.0 pF/m) | 75 Ohm | 70% |
| Voltage Rating |
|---|
| 900 V (Mil-Spec) |
| Operating |
|---|
| -70°C to +200°C |
| Installation Min. |
|---|
| 1 in (25 mm) |
| Max. Pull Tension: | 17 lbs (7.7 kg) |
| Bulk Cable Weight: | 10 lbs/1000ft |
| Environmental Suitability: | Indoor/Outdoor, Indoor, Outdoor, Aerial – When supported by messenger wire |
| Sustainability: | CA Prop 65 |
| Military Compliance: | Commercial, non-QPL product (M17/94-RG179) |
| European Directive Compliance: | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance: | China RoHS II (GB/T 26572-2011) |
| Update and Revision: | Revision Number: 0.502 Revision Date: 11-27-2023 |
| Item # | Color | Putup Type | Length | UPC | Footnote |
|---|---|---|---|---|---|
| 83264 001100 | Brown | Reel | 100 ft | 612825203667 | E |
| 83264 001500 | Brown | Reel | 500 ft | 612825203681 | E |
| 83264 0011000 | Brown | Reel | 1,000 ft | 612825203674 | C E |
