323106A - RS-485, 1 Pr, 22AWG, Str TC, PE Ins, with OS, 1C 22AWG Str, PVC Ins, OA TC Brd, PVC Jkt, AIA, CPE Jkt, CM, PLTC, Sun Res

323106A – RS-485, 1 Pr, 22AWG, Str TC, PE Ins, with OS, 1C 22AWG Str, PVC Ins, OA TC Brd, PVC Jkt, AIA, CPE Jkt, CM, PLTC, Sun Res

Call for Price

Compare
SKU: 323106A Categories: , , ,

Description

Product Overview

Suitable Applications: exposure to rodent, crush, or cut through force, burial, serial communication (RS-485 standard) comprising of PLCs, VFDs, HMIs, motors, RTU, SCADA, etc. within noisy environments over long distance, outdoor such as solar, lighting, etc.

Construction Details

Conductor
Element No. of Elements Size Stranding Material
Pair(s) 1 22 AWG 7×30 TC – Tinned Copper
Conductor(s) 1 22 AWG 7×30 TC – Tinned Copper
Insulation
Element Material Nom. Thickness Color Code Notes
Pair(s) PE – Polyethylene (Foam) 0.033 in (0.84 mm) White/Orange Stripe & Orange/White Stripe HDPE
Conductor(s) PVC – Polyvinyl Chloride 0.017 in (0.43 mm) Blue/White Stripe
Inner Shield
Element Shield Type Material Coverage Notes
Pair(s) Tape Bi-Laminate (Alum+Poly) 100% Single conductor is not under tape
Outer Shield
Shield Type Material Coverage Drainwire Type
Braid Tinned Copper (TC) 65% 22 AWG (7×30) TC
Inner Jacket
Material
PVC – Polyvinyl Chloride
Armor
Armor Type & Material
AIA – Aluminum Interlock Armor
Outer Jacket
Material Nom. Thickness Nom. Diameter
CPE – Chlorinated Polyethylene 0.045 in (1.1 mm) 0.590 in (15.0 mm)
Overall Cable Diameter (Nominal): 0.590 in (15.0 mm)

Electrical Characteristics

Electricals
Element Nom. Characteristic Impedence Nom. Velocity of Prop.
Pair(s) 120 Ohm 78%
Conductor(s)
High Frequency (Nominal/Typical)
Element
Pair(s)
Voltage
UL Voltage Rating
300 V (CM, PLTC)

Standards and Compliance

Environmental Suitability: Outdoor, Sunlight Resistance
NEC / UL Compliance: Article 725, Article 800, CM, PLTC
CEC / C(UL) Compliance: CMG HLBCD

History

Update and Revision: Revision Number: 0.63 Revision Date: 01-14-2024
