123072F - Blue Hose®, 1 Pr #18 Str TC, PP Ins, OS+TC Brd, PVC Jkt, AIA Armor, PVC Jkt, PLTC

123072F – Blue Hose®, 1 Pr #18 Str TC, PP Ins, OS+TC Brd, PVC Jkt, AIA Armor, PVC Jkt, PLTC

Call for Price

Compare
SKU: 123072F Categories: , , ,

Description

Product Overview

Suitable Applications: exposure to rodent, crush, or cut through force, harsh environment, Allen Bradley Data Highway communication interface between PLC processors, I/O devices, operator interfaces, computers and other intelligent devices, PLC processor interlocking, peer-to-peer messaging, remote programming, troubleshooting, I/O updates, etc.

Construction Details

Conductor
Element No. of Elements Size Stranding Material
Pair(s) 1 18 AWG 7×26 TC – Tinned Copper
Insulation
Element Material Nom. Thickness Color Code Notes
Pair(s) PP – Polypropylene 0.025 in (0.64 mm) Blue & White Flame Retardant
Outer Shield
Shield Type Material Coverage Drainwire Type
Tape Bi-Laminate (Alum+Poly) 100% 20 AWG (7×28) TC
Braid Tinned Copper (TC) 55%
Inner Jacket
Material Nom. Diameter
PVC – Polyvinyl Chloride 0.324 in (8.23 mm)
Armor
Armor Type & Material
AIA – Aluminum Interlock Armor
Outer Jacket
Material Nom. Thickness Nom. Diameter
PVC – Polyvinyl Chloride 0.045 in (1.1 mm) 0.617 in (15.7 mm)
Overall Cable Diameter (Nominal): 0.617 in (15.7 mm)

Electrical Characteristics

Electricals
Element Nom. Characteristic Impedence Nom. Velocity of Prop.
Pair(s) 78 Ohm 65%
High Frequency (Nominal/Typical)
Element
Pair(s)
Voltage
UL Voltage Rating
300 V (CM, PLTC), 150 V (ITC)

Mechanical Characteristics

Temperature
UL Temperature
75°C Dry
Table Notes: -40C

Standards and Compliance

Environmental Suitability: Outdoor, Sunlight Resistance
NEC / UL Compliance: Article 725, Article 727, Article 800, CM, ITC, PLTC
CEC / C(UL) Compliance: CMG HL

History

Update and Revision: Revision Number: 0.64 Revision Date: 02-15-2024
