| Suitable Applications: | Microphone, Low Noise for high-EMI environments; Line level balanced analog audio |
| Element | No. of Elements | Size | Stranding | Material |
|---|---|---|---|---|
| Conductor(s) | 4 | 24 AWG | 42×40 | BC – Bare Copper |
| Element | Material | Nom. Thickness | Nom. Insulation Diameter | Color Code |
|---|---|---|---|---|
| Conductor(s) | PE – Polyethylene | 0.016 in (0.41 mm) | 0.056 in (1.4 mm) | Blue, White, Blue/White Stripe, White/Blue Stripe |
| Shield Type | Material | Coverage | Notes |
|---|---|---|---|
| Braid | Tinned Copper (TC) | 92% | Paper tape under braid |
| Material | Nom. Thickness | Nom. Diameter |
|---|---|---|
| PVC – Polyvinyl Chloride | 0.044 in (1.1 mm) | 0.245 in (6.22 mm) |
| Overall Cable Diameter (Nominal): | 0.245 in (6.22 mm) |
| Element | Nom. Conductor DCR | Nom. Capacitance Cond-to-Cond | Nom. Characteristic Impedence | Nom. Velocity of Prop. | Max. Current |
|---|---|---|---|---|---|
| Conductor(s) | 26.6 Ohm/1000ft | 39.2 pF/ft (129 pF/m) | 40 Ohm | 66% | 3.04 Amps per conductor @ 30°C |
| Voltage Rating |
|---|
| 100 V |
| Operating |
|---|
| -30°C to +75°C |
| Stationary Min. | Installation Min. |
|---|---|
| 2.5 in (64 mm) | 2.5 in (64 mm) |
| Max. Pull Tension: | 47.2 lbs (21.4 kg) |
| Bulk Cable Weight: | 33 lbs/1000ft |
| Environmental Suitability: | Indoor (Not Riser or Plenum), Indoor |
| European Directive Compliance: | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance: | China RoHS II (GB/T 26572-2011) |
| Notes: | Quad connection scheme: The two blue wires (or wires directly opposite one another) are connected together to form one conductor, and similarly the two white wires (or remaining wires) are connected together to form the second conductor. |
| Update and Revision: | Revision Number: 0.515 Revision Date: 01-20-2023 |
| Item # | Color | Putup Type | Length | UPC | Footnote |
|---|---|---|---|---|---|
| 1192A B59100 | Black, Matte | Reel | 100 ft | 612825108191 | |
| 1192A B59500 | Black, Matte | Reel | 500 ft | 612825108214 | C |
| 1192A B591000 | Black, Matte | Reel | 1,000 ft | 612825108207 | C |
| 1192A B59N1000 | Black, Matte | Reel w/Small Barrel | 1,000 ft | 612825108184 | C |
| 1192A G7X500 | Blue, Matte | Reel | 500 ft | 612825108269 | |
| 1192A G7X1000 | Blue, Matte | Reel | 1,000 ft | 612825108252 | C |
| 1192A U901000 | Gray, Matte | Reel | 1,000 ft | 612825108283 | C |
| 1192A G7W1000 | Green, Matte | Reel | 1,000 ft | 612825108245 | C |
| 1192A G7WN1000 | Green, Matte | Reel w/Small Barrel | 1,000 ft | 612825108238 | C |
| 1192A G8C1000 | Purple, Matte | Reel | 1,000 ft | 612825350118 | |
| 1192A G8CN1000 | Purple, Matte | Reel w/Small Barrel | 1,000 ft | 612825350101 | |
| 1192A G7V1000 | Red, Matte | Reel | 1,000 ft | 612825108221 | C |
| 1192A G8M1000 | Yellow, Matte | Reel | 1,000 ft | 612825108276 |
