| Suitable Applications: | Microphone, Low Noise for high-EMI environments; Line level balanced analog audio |
| Element | No. of Elements | Size | Stranding | Material |
|---|---|---|---|---|
| Conductor(s) | 4 | 26 AWG | 30×40 | BC – Bare Copper |
| Element | Material | Nom. Thickness | Nom. Insulation Diameter | Color Code |
|---|---|---|---|---|
| Conductor(s) | PE – Polyethylene | 0.013 in (0.33 mm) | 0.045 in (1.1 mm) | Blue, White, Blue/White Stripe, White/Blue Stripe |
| Shield Type | Material | Coverage | Drainwire Type | Notes |
|---|---|---|---|---|
| French Braid | Tinned Copper (TC) | 95% | 28 AWG (19×40) BC | Paper tape under braid with drain over tape |
| Material | Nom. Thickness | Nom. Diameter |
|---|---|---|
| PVC – Polyvinyl Chloride | 0.031 in (0.79 mm) | 0.190 in (4.83 mm) |
| Overall Cable Diameter (Nominal): | 0.190 in (4.83 mm) |
| Element | Nom. Conductor DCR | Nom. Capacitance Cond-to-Cond | Nom. Velocity of Prop. | Max. Current |
|---|---|---|---|---|
| Conductor(s) | 36 Ohm/1000ft | 39.2 pF/ft (129 pF/m) | 66% | 2.32 Amps per conductor @ 30°C |
| Voltage Rating |
|---|
| 100 V |
| Operating |
|---|
| -20°C to +60°C |
| Stationary Min. | Installation Min. |
|---|---|
| 1.9 in (48 mm) | 1.9 in (48 mm) |
| Max. Pull Tension: | 37.5 lbs (17.0 kg) |
| Bulk Cable Weight: | 25 lbs/1000ft |
| Environmental Suitability: | Indoor (Not Riser or Plenum), Indoor |
| European Directive Compliance: | EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance: | China RoHS II (GB/T 26572-2011) |
| Notes: | Quad connection scheme: The two blue wires (or wires directly opposite one another) are connected together to form one conductor, and similarly the two white wires (or remaining wires) are connected together to form the second conductor. |
| Update and Revision: | Revision Number: 0.523 Revision Date: 01-20-2023 |
| Item # | Color | Putup Type | Length | UPC | Footnote |
|---|---|---|---|---|---|
| 1172A B59500 | Black, Matte | Reel | 500 ft | 612825107774 | |
| 1172A B591000 | Black, Matte | Reel | 1,000 ft | 612825107767 | C |
| 1172A B59N1000 | Black, Matte | Reel w/Small Barrel | 1,000 ft | 612825367055 | |
| 1172A G7X1000 | Blue, Matte | Reel | 1,000 ft | 612825107804 | |
| 1172A U901000 | Gray, Matte | Reel | 1,000 ft | 612825107835 | |
| 1172A G7W1000 | Green, Matte | Reel | 1,000 ft | 612825107798 | |
| 1172A G8C1000 | Purple, Matte | Reel | 1,000 ft | ||
| 1172A G7V1000 | Red, Matte | Reel | 1,000 ft | 612825107781 | |
| 1172A G7Y1000 | White, Matte | Reel | 1,000 ft | 612825107811 | |
| 1172A G8M1000 | Yellow, Matte | Reel | 1,000 ft | 612825107828 |
