Fiber Optic Jumper – Jumper, Duplex, SC/APC – SC/APC. 3.0mm, 10meter Jumpers (065-512-10-ML) – Multilink

Description

General Specifications

Cable Length

10 Meter

Application

Riser RatedGeneral Building ApplicationsIndoor HorizontalOuter Jacket Color

Yellow

Polish #1

APC

Cable Assesmbly Type

Duplex Fiber

Polish #2

APC

Fiber Count

2

Nominal Outer Diameter

3.6mm

Flame Rating

Riser Rated OFNRFiber Specifications

Cable Type

Singlemode 3.0mm Duplex Zipcord 9/125µm Tight Buffered Bend Insensitive G657 A1

Reflectance, Typical #2

< -65 dB Fiber Category Singlemode (OS1) Reflectance, Typical #1 < -65 dB Insertion Loss Typical 0.12 dBConnector Specifications Connector Type SC/APC Ferrule Material Zirconia Housing Material Composite Housing Color Green Boot Color Green
